Grain Sheds For Effective
& Efficient Storage.
Securely store produce in a custom produce
and grain storage shed
Action storage sheds are a cost-effective bulk storage option for on-farm and grain receival sites.
A Smarter Way To Store Grain
A grain shed is the most cost-effective long-term and secure bulk storage option for grain, storing larger volumes at a significantly lower cost per tonne than silo storage.
Get the design right and you also protect grain quality, speed up loading and unloading, and open up more market opportunities.
A grain shed is also a highly versatile farming storage asset. Store grain at harvest, fertiliser at sowing, and machinery in the off-season, all from the one shed.
You can access the grain storage calculator under the Sizing tab below
Best-Practice Grain Shed Configuration:
- Fully-enclosed shed, with concrete panel walls.
- Standard span widths include 18m for smaller-scale storage, and 24m or 27m for larger bulk facilities. A 27m span lets a truck turn inside the shed.
- Popular eave heights range from 6.75m to 9m, matched to your truck access and clearance needs.
- A 21 degree roof pitch is recommended, accommodating grain’s angle of repose and allowing a truck to tip inside the shed.
- Concrete panel walls at 3m to 3.5m, with 3.5m the most cost-effective and functional option. Movable L-walls run 2.4m or 3m, giving you segregation without losing capacity.
- Customise further with sliding doors and cantilevered canopies for sheltered access.
Our building consultants can provide advice on details like bulk density, angle of repose and turning circles to ensure your storage set up is effective and functional.
For project specific advice, talk to the team at Action Steel. Call 1800 687 888.
FumoFlow Grain Sheds By Action
There’s a new way to treat grain! Action has designed and developed a fumigation recirculation and ventilation system for grain sheds.
Discover how the patent-pending FumoFlow grain sheds make treating grain safer, easier and more effective at fumoflow.au.
Grain Shed Options
Helpful Articles
Euston Park’s Potato Cool Store Saving Time & Money
Purpose built potato cool store sheds have been popular investments over the past twelve months. Growers are looking to mitigate rising off-farm storage costs and increase handling efficiencies And...
6000 Tonne Storage Shed A Smart Investment For Darcra Farming
On-farm storage and multi-use sheds have been popular projects over the past 12 months – and with input and market prices fluctuating, this is proving to be a smart move. We...
Concrete Panel Grain Sheds: Pros, Cons & Prices
Researching concrete panel grain sheds? Are they a good fit for your grain storage? Grain sheds continue to prove to be excellent investments, providing a low storage cost per...
Sizing
Grain Calculator
To help you determine the best shed size for storing grain, use this calculator.
Put in your shed size and grain type and the storage volume and total tonnage will be displayed.
Standard Farm Shed Sizes
& Designs
The standard shed spans and sizes we offer have been extensively researched and designed to suit agricultural and farming operations.
If you require a particular size and shape please don’t hesitate to contact us and speak with one of our shed professionals.
| Span | Length | Height | Bay Size | ||
|---|---|---|---|---|---|
| 15m (50ft) | x | 24m | x | 6m | 8m |
| 15m (50ft) | x | 32m | x | 6m | 8m |
| 18m (60ft) | x | 32m | x | 6m | 8m |
| 18m (60ft) | x | 40m | x | 6m | 8m |
| 21m (70ft) | x | 32m | x | 6m | 8m |
| 21m (70ft) | x | 40m | x | 7.5m | 8m |
| 24m (80ft) | x | 40m | x | 6m | 8m |
| 24m (80ft) | x | 40m | x | 7.5m | 8m |
| 24m (80ft) | x | 48m | x | 7.5m | 8m |
| 24m (80ft) | x | 64m | x | 7.5m | 8m |
| 24m (80ft) | x | 80m | x | 7.5m | 8m |
| 30m (100ft) | x | 56m | x | 7.5m | 8m |
Design Ideas
Design Options & Ideas for
Your Farm Shed
We offer a range of options to help you customise and tailor you farm shed to suit your needs.
Learn about these options and discuss your farm shed project design with our building consultants.
Cladding
Australian-Made Steel Cladding
We offer two cladding profiles for your shed project – Trimclad® or corrugated iron.
While most of our farm shed build are clad with zinc cladding, we do also offer Colorbond cladding.
If you aren’t sure which options would best suit your shed project, our guide helps explain the advantages and disadvantages of the two products.
Euston Park’s Potato Cool Store Saving Time & Money
Purpose built potato cool store sheds have been popular investments over the past twelve months. Growers are looking to mitigate rising off-farm storage costs and increase handling efficiencies And...
6000 Tonne Storage Shed A Smart Investment For Darcra Farming
On-farm storage and multi-use sheds have been popular projects over the past 12 months – and with input and market prices fluctuating, this is proving to be a smart move. We...
Concrete Panel Grain Sheds: Pros, Cons & Prices
Researching concrete panel grain sheds? Are they a good fit for your grain storage? Grain sheds continue to prove to be excellent investments, providing a low storage cost per...
Grain Calculator
To help you determine the best shed size for storing grain, use this calculator.
Put in your shed size and grain type in the left side fields and the storage volume and total tonnage will be displayed on the right.
Standard Farm Shed Sizes
& Designs
The standard shed spans and sizes we offer have been extensively researched and designed to suit agricultural and farming operations.
If you require a particular size and shape please don’t hesitate to contact us and speak with one of our shed professionals.
| Span | Length | Height | Bay Size | ||
|---|---|---|---|---|---|
| 15m (50ft) | x | 24m | x | 6m | 8m |
| 15m (50ft) | x | 32m | x | 6m | 8m |
| 18m (60ft) | x | 32m | x | 6m | 8m |
| 18m (60ft) | x | 40m | x | 6m | 8m |
| 21m (70ft) | x | 32m | x | 6m | 8m |
| 21m (70ft) | x | 40m | x | 7.5m | 8m |
| 24m (80ft) | x | 40m | x | 6m | 8m |
| 24m (80ft) | x | 40m | x | 7.5m | 8m |
| 24m (80ft) | x | 48m | x | 7.5m | 8m |
| 24m (80ft) | x | 64m | x | 7.5m | 8m |
| 24m (80ft) | x | 80m | x | 7.5m | 8m |
| 30m (100ft) | x | 56m | x | 7.5m | 8m |
Design Options & Ideas for
Your Farm Shed
We offer a range of options to help you customise and tailor you farm shed to suit your needs.
Learn about these options and discuss your farm shed project design with our building consultants.
Australian-Made Steel Cladding
We offer two cladding profiles for your shed project – Trimclad® or corrugated iron.
While most of our farm shed build are clad with zinc cladding, we do also offer Colorbond cladding.
If you aren’t sure which options would best suit your shed project, our guide helps explain the advantages and disadvantages of the two products.
Grain & Produce Storage Shed Project Gallery
27m x 39m x 7.5m grain shed
Skipton, VIC
27m x 45.5m x 8.25m grain shed
Lismore, VIC
18m x 32.5m x 6.5m grain shed
Mount Bute, VIC
91m x 27m x 6.75m grain sheds
Tutye, VIC
56m x 40m x 8.5m produce shed with 10m canopy
Bannerton, VIC
36m x 18m x 6.75m grain shed
Ullswater VIC
71.5m x 27m x 7.5m grain shed
Ardlethan NSW
71.5m x 27m x 7.5m grain shed
Lockhart NSW
58.5m x 27m x 7.5m grain shed
Prairie VIC
71.5m x 27m x 7.5m grain sheds
Donald VIC
60m x 21m x 6m grain shed
Moree NSW
78m x 27m x 7.5m grain shed with 12m canopy
Bullarah NSW
29m x 24m x 8.25m potato cool store
Holbrook NSW
32.5m x 18m x 7.5m grain/fertiliser shed
Laen VIC
32.5m x 21m x 7.5m grain shed
Nareewilllock VIC
80m x 21m x 7.5m produce storage
Mount Gambier SA
45m x 30m x 8.25m produce storage
Penola SA
51m x 24m x 7.5m machinery/grain shed with 12m skillion
Warmur VIC
39m x 27m x 8.25m grain/fertiliser shed
NSW
45m x 36m x 8.6m potato storage shed
Euston NSW
68m x 24m x 7.5m grain shed with 12m canopies
Watchem VIC
76.8m x 27m x 6m grain/fertiliser shed
Bellata NSW
39m x 21m x 7m grain/fertiliser shed
Kinnabulla VIC
48m x 18m x 7.5m almond storage shed
Red Cliffs VIC
96m x 30m x 7.5m grain shed
Streatham VIC
68.75m x 27m x 7.5m grain shed
Dundonnell VIC
68.75m x 27m x 7.5m grain shed
Dundonnell VIC
24m x 18m x 6.75m fertiliser shed with concrete panel walls
Wareek VIC
102m x 36m x 6m grain shed with concrete panel walls
Smeaton VIC
60m x 30m x 6m grain shed with overhead loading system
Lismore VIC
60m x 30m x 6m grain shed with concrete panel walls
Lismore VIC
30m x 12m x 4.3m inside-out grain shed
Windermere VIC
37m x 21m x 5m inside-out grain shed
Maroona VIC
81m x 40m x 9m grain storage shed
Stockyard Hill VIC
81m x 40m x 9m grain shed
Stockyard Hill VIC
Contact our expert building consultants today to discuss your requirements!
1800 68 78 88
QUOTE REQUEST
QUOTE REQUEST
Please take the time to fill in the below form and one of our Product Consultants will be in touch with you shortly.
No spam. No pressure.
We’ll look at your project, give you a straight-up recommendation and price, and let you decide in your own time.
PLEASE NOTE: WE DON’T BUILD ANY SHEDS SMALLER THAN 12M SPAN BY 24M LONG.
